● With stable engine Jiangxi Isuzu JE493 Engine, high power & Low fuel consume, Equipped with Getrag Transmission.
● Optimized design for Axle and Propeller Shaft, Reinforced Frame, high-strength beam and rear suspension leaf spring
bring super load-carrying performance.
● Humanized design provides comfortable diving experience and enhances driving safety.
● Low fuel consumption: 10L Per 100 kilometer.
| Model | T300 | ||||
|---|---|---|---|---|---|
| Type | Single cab flatbed truck | Space cab flatbed truck | Single cab box truck | Single cab fence truck | |
| DIMENSION & WEIGHT | Overall size(LxWxH) (mm) | 5995×2020×2320 | 5995×2020×2320 | 5995×2020×2960 | 5995×1990×3015 |
| Wheelbase (mm) | 3360 | ||||
| Cargo size(LxWxH) (mm) | 4155×1940×380 | 3755×1940×380 | 4080×1940×1930 | 4045×1890×380 | |
| Tread, front - rear (mm) | 1604 / 1586 | ||||
| Suspension (Front / Rear) (mm) | 1125 / 1510 | ||||
| Min. Ground Clearance (mm) | 233 | ||||
| Approach/ Departure Angle (°) | 19 / 16 | ||||
| Max. Gross Vehicle Mass (kg) | 6000 | ||||
| Curb vehicle weight (kg) | 2595 | 2655 | 2890 | 2840 | |
| Payload (kg) | 3210 | 3150 | 2915 | 2965 | |
| Seating capacity (Persons) | 3 | ||||
| Axle Quantity | 2 | ||||
| SYSTEM | Gearbox | 5-speed manual transmission | |||
| Suspension Plate Spring Quantity (front/rear) | 8/9+5 | ||||
| Steering | Recirculating ball | ||||
| Driving Brake | ABS+ Air Brake | ||||
| Parking Brake | Air Cut Brake | ||||
| Steering Assitant | Vacuum booster | ||||
| Front/Rear Brake | Drum Brake | ||||
| Steel Rim | 16×5.50K | ||||
| Tyre type/Pressure | 7.00R16/560Kpa | ||||
| Driving tyre (pc) | 6 | ||||
| Spare tyre (pc) | 1 | ||||
| Max. vehicle speed (km -h) | 100 | ||||
| ENGINE | Engine model | JE493ZLQ5 | |||
| Fuel type | Diesel | ||||
| Type | High Pressure Common Rail + Turbocharged intercooled + DOC+SCR | ||||
| Displacement (cc) | 2771 | ||||
| Max. power (kw -rpm) | 85 /3200 | ||||
| Max. torque (N.m -rpm) | 285 /2000 | ||||
| Emission | Euro V | ||||
| Fuel tank (L) | 83 | ||||
