Specially developed for business market, smart and broad space, delicate and luxurious interior, fashionable appearance design, reflects classical aesthetics everywhere, reveals strong business atmosphere, to provide a full range of multiple needs for the enjoyment of infinite comfortable business trip
LUX Type
LUX Type
LUX Type
LUX Type
LUX Type
LUX Type
LUX Type
LUX Type
LUX Type
LUX Type
ECO Type
ECO Type
ECO Type
ECO Type
ECO Type
ECO Type
| Model (LHD/RHD) | J5 | |||
|---|---|---|---|---|
| DIMENSION & WEIGHT | Overall dimension (LxWxH) (mm) | 5380x1880x2285 | ||
| Wheelbase (mm) | 3110 | |||
| Tread, front/ rear (mm) | 1655/1650 | |||
| Min. ground clearance (mm) | 155 | |||
| Inner height(for passenger) (mm) | 1555 | |||
| Curb vehicle weight (kg) | 2130 (gasoline) / 2205 (diesel) | |||
| Gross vehicle weight (kg) | 3300 (gasoline) / 3450 (diesel) | |||
| Seating capacity (persons) | 14-17 | |||
| Fuel tank capacity (L) | 70 | |||
| Tires | 195R15C | |||
| ENGINE | Model | 4RB2 | G4BA | |
| Fuel type | Gasoline | |||
| Type | Four stroke, water cooling, in-line, 16-valve, DOHC, EFI | Four stroke, water cooling, in-line, 16-valve, DOHC | ||
| Piston displacement (cc) | 2438 | 2693 | ||
| Compression ratio | 9.2:1 | 9.5:1 | ||
| Max. power (kw/rpm) | 102/4600-5000 | 110/4800 | ||
| Max. torque (N.m/rpm) | 217/2600-3200 | 240/2800-3600 | ||
| Fuel consumption (L/100km) | 11.3 | |||
| Emission | Euro Ⅲ / Euro IV | Euro Ⅲ | ||
| Technology source | TOYOTA | |||
| SYSTEM | Steering system | Pinion-and-rack | ||
| Suspension | Front | Double wishbone independent suspension | ||
| Rear | Variable rate leaf spring | |||
| Braking system | Hydraulic braking system with vacuum booster front disc/rear drum | |||
| Clutch type | Single disc, hydraulic control | |||
| Gearbox | 5 speed manual | |||
| Max. gradeability (〫) | ≥30 | |||
